Digital Intelligent Terminal (IT)

Digital Intelligent Terminal (IT)
Digital Intelligent Terminal (IT)
Product Code : 12
Product Description

Digital Intelligent Terminal (IT)

“IIT 4500” is a specially designed weighbridge application intelligent terminal for digital loadcells. Use of pre-calibrated digital loadcells enable fast installation, service support thus increasing overall productivity and reduction in downtime. Features of weighing, data processing, saving, printing makes it a stand-alone utility for public and industrial weighbridges. ‘IIT 4500’ is robust in nature to withstand harsh environmental conditions. It can operate reliably over a wide temperature range and also in humid weather.

Hardware Features

  • 32 bit ARM processor
  • Front mount 16x2 LCD display & 0.5inch LED display
  • SMPS power supply
  • On board memory to save 1lakh records
  • USB ports for Standard computer keyboard&pen drive
  • Centronics port for 80 column Dot matrix Printer
  • RS232 port for display/GSM modem/continuous weight transmission
  • Table top port for connecting external wired displays
  • Inbuilt wireless trans - receiver (Optional)

Software Features “Installation privilege”

  • Initial LCD display message field settable as OEM name/ weighbridge name
  • Installation settings secured under engineer login
  • Engineer login password field settable by authorised OEM
  • Three types of cornering features available
  • Smart Calibration
  • Multi-step smart calibration
  • Installation report
  • Mandi Application feature of Rate, Amount, Binding material deduction etc.

Software Features “Weighbridge privilege”

  • Simple process for weighments of Tare/ Gross Vehicle weights
  • 10 entries in ticket for 25 characters each
  • 4 code banks for 100 codes each( Flexibility of setting)
  • Field settable header, footer, signature lines
  • Facility to view/print earlier saved records according to RST no/ Vehicle no
  • Multiple report option all/summary/filtered/serial no. wise/date wise/time wise
  • Dumping of report into pen drive to avail softcopy of records (.xls)
  • Field settable Pre-printed tickets
  • SMS feature in 3 different ways
  • Net weight printing in words
  • Mandi Application feature of Rate, Amount, Binding material deduction etc.

Application

  • Public Weighbridges
  • Industrial Weighbridges
  • Toll Ways

IIT Features

  • Long Distance between weighbridge room and structure
  • Lower division size can be obtained, leading to higher accuracy of scale
  • Special OEM specific DLC interlocking
  • Field settable number of loadcells, upto 16
  • Simple and fast Installation
  • No need of manual cornering using trimpots & calibration with test weights.
  • Automatic fault diagnosis with warning of particular DLC
  • Installation report

Salient Features

  • Available to work with pre-calibrated Appalto DLC's
  • Working with zemic/ ningbo/ thames side/ flintec or other DLC's (OPTIONAL), features may vary in IIT for these DLC’s
  • Configuration Upload/download through pendrive
  • Maximum Utilisable Memory, field selectable by OEM upto 1 lakh
  • Barr Overloading feature especially useful for industries
  • Memory Status Display
  • Field setting option for Vehicle wise working
  • USB port for pen drive connectivity (data in .xls format)
  • SMS provision
  • Field settable pre-printed stationary
  • Mandi Application features

Scope of Supply

  • IIT 4500
  • Power cable
  • Load cell connector
  • Printer isolator cable

Optional Features

  • Confidential Report
  • Inbuilt wireless for connecting wireless accessories (JB, display)
  • Graphical display
  • Housing choices available

Technical Specifications

Processor 32bit ARM Processor
Processor clock frequency 50 MHz
Real time clock On board battery backed RTC
Memory On board memory to save 1 Lakh records
Power supply
Input Voltage 90V to 270V AC @ 50Hz
Protection * 750mA fuse for input AC mains
* Input line filter for EMI and RFI suppression
* Spike suppressor for input transients
* Opto-isolation of signals and I/Os for high immunity from electricalnoise
Power Consumption 10 VA (approx.)
Load cell excitation 13.5 DC with 300 mA current capability
Display 16 characters by 2 line LCD display with backlight for displaying numerals and alphabets & 1/2" LED 7 segment red display to show weight.
Keyboard port 101-key with USB connector compatible keyboard. (Recommended for use Logitech or Microsoft)
USB Port USB Port configured for Pen Drive
Printer port Isolated Centronics compatible printer port provided on rear panel for connecting 80-column dot matrix printer for printing of weighment record and reports
Serial port Isolated RS-232 serial port is provided for continuous weight transfer
Remote Display Port Remote display port is provided to connect optional 1/2inch, 1inch,2.3inch or 4inch bright red LED display to indicate the weight on the platform.
Environment Operating temperature: 0℃ to 55℃
Humidity up to 95% RH non-condensing
